Product Features：
- The body is designed with a streamlined shape and tempered glass.
- A spray nozzle is located at the upper rear of the vehicle body,providing water spraying for dust suppression on the working surface.
- Equipped with vacuum tires for wear resistance and long service life.
- The vehicle body is coated with high-temperature metallic paint and features corrosion-resistant materials such as electrophoresis and spray coating for rust prevention.
Specification Item Details Product Name Four-Wheel Self-Dumping 880L Pure Suction Sweeper Rated Occupancy 1 person Body Color Dark Grey (Logo Customization Available) Overall Dimensions (L × W × H) 3500 * 2300 * 2100 mm Wheelbase 930mm Wheel Track 1620mm Ground Clearance 100mm Curb Weight 960 kg Maximum Speed 25 km/h Working Speed 12 km/h Minimum Turning Radius 4.5 m Maximum Climbing Angle ≤25° Operating Time 3-5 H Full Load Operating Time ≥ 3 H Water Tank Capacity 160 L Garbage/Hopper Capacity 880 L Sweeping Width 2300 mm Front Brush Diameter 700 mm Side Brush Diameter 600 mm Maximum Dumping Height 2750 mm Suction Inlet Width 800 mm Tires 135/70R12 Vacuum Tires Steering Type Mechanical Steering Wheel Braking System Rear Wheel Hydraulic Drum Brakes, Handbrake for Parking Handheld High-Pressure Gun 1 unit (includes 0°, 15°, 25° nozzles) High-Pressure Hose Reel 10 meters Rear Spray Nozzle 1000mm Seven-Hole Watering Nozzle High-Pressure Pump 1500W Main Fan DC Brushless Fan 60V 5000W Drive Controller 60V 3000W DC Controller Drive Motor 60V 3000W DC Motor Battery 60V 300Ah Lithium Battery (Lithium Upgrade Optional) Charger Portable Smart Charger Charging Time 6-8 Hours Cabin Structure Enclosed Frame Steel Cabin with Glass Doors Instrument Panel Electronic Display Meter Seat Leather Soft Seat with Cushion Rearview Mirror Wide-Angle, Blind Spot-Free Camera & Safety Reversing Camera, Reversing Alarm Lighting Warning Lights + LED Roof Light + LED Side Turn Signals + LED Arrow Lights + Tail Lights Convenience USB Charging Port, Electronic Cigarette Lighter, Ashtray, Cup Holder
