Note:Standard double fan,optional with sunshade.
Machine performance:The combination of suction,sweeping, and spraying effectively suppresses dust and thoroughly cleans ground waste and dust.
Place of use:Used for cleaning workshop,parks,streets,lanes.docks，property communities, warehouses,sports venues,schools,airports,and other areas in the factory area. The cleaning efficiency is 10 times that of the traditional manual cleaning,and one sweeper can replace 8-2 leaner.
| Parameter | Value / Specification |
| Model | TS-14C |
| Sweeping Width | 1400 mm |
| Main Brush Width | 700 mm |
| Working Efficiency | 9000 – 15000 m²/h |
| Working Time | 2 – 6 h |
| Dustbin Capacity | 160 L |
| Side Brush Diameter | 500 mm |
| Travel Speed | 0 – 20 km/h |
| Overall Dimensions (LWH) | 2200 * 1400 * 1480 mm |
| Water Tank Capacity | 80 L |
| Vacuum Filtration Area | 6 m² |
| Tire Type | Front: 350-12, Rear: 350-10 (Pneumatic) |
| Control Mode | Intelligent Control System (Timed Dust Shaking Function) |
| Headlight | Four-way LED Headlights |
| Taillight | Integrated Taillights (Turn Signal + Brake + Running) |
| Warning Light | Roof-mounted Operation Warning Light |
| Type | Maintenance-free Lead-Acid (Lithium Battery Optional) |
| Battery Capacity | Standard: 48V-63AH*4 / 80AH*4 / 100AH*4 (Lead-Acid) |
| Drive Motor | 800 W Intelligent Gear Shift |
| Main Brush Motor | 1000 W |
| Side Brush Motor | 2 * 100 W |
| Motor Voltage | 48 V |
| Model | Dedicated for Sweeping Vehicles |
